Phosphine PH3 Fumigation Gas Detector Sound / Light Gas Aalrm With Display

Name: Phosphine PH3 Fumigation Gas Detector Sound Light Gas Aalrm With Display
Brand: YuanTe
Price: 1 USD

Brand Name : YuanTe

Model Number : YT-95H-PH3-A

Certification : CE CNEX ISO9001-2015

Place of Origin : China

MOQ : 1

Price : Negotiable

Payment Terms : T/T, Western Union

Supply Ability : 500PCS/DAY

Delivery Time : 2-3 days

Packaging Details : Carton Box

Detected Gas : Phosphine PH3

Measure Range : 0-5ppm, 0-10ppm,0-20ppm,0-50ppm,0-100ppm,0-200ppm,0-500ppm,0-1000ppm, 0-2000ppm.

Color : Blue

Packing : Paper Box

Install Method : Wall-mounted, Piping-type, Flow-type

Power : 12-36Vdc

Contact Now

Phosphine PH3 Fumigation Gas Detector Gas Aalrm with Display

Characteristics:
1. Standard equipped with three-wire system 4-20mA analog output; relay output; RS485 output.
2. Unique infrared ray control function, which can non-contacted control the device.
3. Being compatible with all kinds of controlled alarms, PLC, DCS and other control system, can be remote monitored.
4. Alarm mode is sound and light, alarm point is settable.
5. Explosion-proof design, fast, reliable and stable.
6. Explosion-proof grade: Ex dⅡCT6
7. With self-calibration function, and three standard keys will be used to realize on-site maintenance.
8. Detachable probe/gas cell: It is very easy to calibrate and replace sensor

Technical Parameters:

Gas detected	Phosphine PH3
Detection principle	Electrochmistry
Install method	Wall-mounted, piping type, flow-type (according to the detected environment)
Measure range	0-5ppm, 0-10ppm,0-20ppm,0-50ppm,0-100ppm,0-200ppm,0-500ppm,0-1000ppm, 0-2000ppm.
Resolution	0.001ppm, 0.01ppm, 0.1ppm, 1ppm
Precision	≤± 1-2% FS
Signal output	4-20mA, 0-5V, RS485, relay(optional)
Response time	≤10S	Recovery time	≤10S
Repeatability	≤±1%	Linearity error	≤±1%
Zero shift	≤±1%(FS/year)	Display	High-light nixie tube display
Connection mode	G1/2 external thread explosion-proof flexible pipe	Unit	ppm
Temperature	-20 to 50°C	Humidity	0-95%RH
Explosion-proof	Ex dⅡCT6	Degree of protection	IP65
Alarm	Sound, light	Operating time	24H
Dimensions	18015090mm	Weight	≤2kg

Funtions:
1. Monitor the Phosphine PH3 gas in environment or pipeline.
2. With self-calibration and zero calibration function, makes the detection more accurate and reliable.
3. With temperature compensation, this is able to realize gas concentration compensation under conditions of different temperatures.
4. Infrared ray controller can remote control alarm point settings, zero calibration, and address modification. (optional)
5. Can output one or two on-off signals, can drive ventilator or solenoid valve and other external devices. (optional)
6. Working Voltage:24V DC
7. Case: die-cast aluminum

Phosphine PH3 Fumigation Gas Detector Sound / Light Gas Aalrm With Display
